Bafang Geared Hub Motor
1000W(peak 1270W/ 95 Nm)
48V 20Ah
Battery
26x4"
Fat Tire
Up to 80Miles
Average Range
400lbs
Maximum Load
28Mph
Maximum Speed
Apex Full Suspension Fat Tire Ebike 1000W
D4HT3
$1,899
| Save $920 (33%)
Free Shipping
15 Day Returns
2-Year Warranty
1000W(peak 1270W/ 95 Nm)
Bafang Geared Hub Motor
48V 20Ah
Battery
26x4"
Fat Tire
Up to 80Miles
Average Range
400lbs
Maximum Load
28Mph
Maximum Speed
Add to cart
Full Suspension
It features a front fork suspension and a rear shock absorber, allowing the bike to absorb impacts from bumps, rocks, and uneven surfaces. This suspension system helps to smooth out the ride, reduce vibrations, and improve overall comfort.
1000W Bafang Motor
Apex eBike is equipped with a robust 1000W brushless motor, delivering impressive electric power and reaching speeds of up to 28 mph. With its fast peak torque output and excellent acceleration performance, you can conquer climbs without any frustration.
48V 20A Battery
Apex features a 48V 20A battery, providing ample energy for your adventures. On a full charge, you can expect a remarkable range of 80+ miles, allowing you to explore farther and embrace longer rides with confidence.
WELL-BRAND COMPONENTS
TEKTRO® Hydraulic brakes
180mm disc brake system, smooth braking with quick response and rapid heat dissipation, combined with the automatic power-off function of brake, greatly shorten the braking distance.
SHIMANO® 7-Speed Shift System
It allows you to shift up or down quickly even when riding at high speed. Choose the suitable freewheel under the different riding conditions, it will improve the riding efficiency.
Kenda® All-terrain Tires
The 26*4'' tires stay safe with an improved tougher compound and aggressive tread pattern to prevent tires damage. Tires tread pattern Enhanced wet traction and reduced risk of hydroplaning.
KMC® Rust-proof Chain
Equip with world-class KMC chain, it is designed to easily withstand extreme weather conditions, including salt, high humidity, snow and rain storm.
VELO® Saddle
The Velo Bicycle Saddle provides excellent support on your sit bones with almost no pressure to the perineum area.
Rear Suspension
Our rear suspension system ensures optimalstability, keeping your electric bike firmly plantedon any terrain. Feel confident and in control,whether you're cruising on the streets or tacklingoff-road trails.
Full-color LCD Display
A real-time view of the battery and riding information is shown in the display. Colorful icons avoid visual fatigue effectively. The LCD backlight is clearly visible at night or in the sun. IPX4 waterproof and dustproof construction assure it is always in good condition.
1
2
3
4
5
6
7
TEKTRO® Hydraulic brakes
180mm disc brake system, smooth braking with quick response and rapid heat dissipation, combined with the automatic power-off function of brake, greatly shorten the braking distance.
SHIMANO® 7-Speed Shift System
It allows you to shift up or down quickly even when riding at high speed. Choose the suitable freewheel under the different riding conditions, it will improve the riding efficiency.
Kenda® All-terrain Tires
The 26*4'' tires stay safe with an improved tougher compound and aggressive tread pattern to prevent tires damage. Tires tread pattern Enhanced wet traction and reduced risk of hydroplaning.
KMC® Rust-proof Chain
Equip with world-class KMC chain, it is designed to easily withstand extreme weather conditions, including salt, high humidity, snow and rain storm.
VELO® Saddle
The Velo Bicycle Saddle provides excellent support on your sit bones with almost no pressure to the perineum area.
Rear Suspension
Our rear suspension system ensures optimalstability, keeping your electric bike firmly plantedon any terrain. Feel confident and in control,whether you're cruising on the streets or tacklingoff-road trails.
Full-color LCD Display
A real-time view of the battery and riding information is shown in the display. Colorful icons avoid visual fatigue effectively. The LCD backlight is clearly visible at night or in the sun. IPX4 waterproof and dustproof construction assure it is always in good condition.
Technical Specification
| Battery | 48V 20Ah (960Wh)LG cell | Brake calipers | Tektro Hydraulic brakes |
| Motor | 48V 1000W Bafang Geared Hub Motor | Chain | KMC C7NP |
| USB ports | 5V | Fork | Aluminum Alloy Integrated suspension front fork |
| Hightlight | 45LUX | Frame | 6061 aluminum alloy |
| Tail Light | Integrated light | Freewheel | Shimano 7-speed freewheel 14-34T |
| Spokes | 12-gauge stainless steel | Handlebars | Custom formed aluminum |
| Charger | 48V3A | Kickstand | Single-leg aluminum alloy |
| Pedal Assist | Intelligent 5 level pedal assists | Pedals | Wellgo mountain type |
| Recommended Rider Height | Above 5'7'' | Rims | Alloy, Star Circle, 36H |
| Total Payload Capacity | 400 lbs | Saddle | Leather comfort seat |
| N.W. | 81.6 lbs | Seat post | Promax ∮31.8*350MM | Tires | 26x4.0 Kenda all-terrain Tires with reflective patches and puncture-proof | Throttle | Twist throttle |
| Sensor | Torque Sensor |
Geometry
| A | Handlebar Height 46.8" |
| B | Total Length 79.5" |
| C | Wheelbase 51.1" |
| D | Wheel Size 26" x 4.0" |
| E | Seat Height 33.5"-42.5" |
| F | Stand Over Height 29.1" |
| G | Chain Stay Length 20.5" |
| I | Handlebar Reach 22.8" |
| J | Head Tube 5.9" |
| K | Seat Tube Length 17.7" |
Distance Range
| PEDAL-ASSIST | |||||
|---|---|---|---|---|---|
|
PAS
|
1 | 2 | 3 | 4 | 5 |
|
Standard Range
|
141 Miles | 87 Miles | 70 Miles | 47 Miles | 31 Miles |
| THROTTLE ONLY | ||||||
|---|---|---|---|---|---|---|
|
Standard Range
|
30 Miles | empty | empty | empty | empty | empty |
*The above data is calculated based on a load of 165lbs, zero wind resistance, and a temperature of 25°C, with no uphill conditions.
Distance Range
PEDAL-ASSIST
PAS
1
2
3
4
5
Standard Range
141 Miles
87 Miles
70 Miles
47 Miles
31 Miles
THROTTLE ONLY
Standard Range
30 Miles
*The above data is calculated based on a load of 165lbs, zero wind resistance, and a temperature of 25°C, with no uphill conditions.
HJM Apex eBike offers an exceptional riding experience with its front and rear suspension systems. These systems are specifically designed to provide enhanced comfort, control, and performance, ensuring a smooth and enjoyable ride even on rough and challenging terrains. With its robust construction and off-road capabilities, Apex eBike is the perfect companion for all your outdoor adventures. Whether you're conquering mountain trails, exploring forest paths, or cruising along the beach, this full suspension All-Terrain Fat Tire eBike is built to handle any terrain with ease and confidence. Get ready to embark on thrilling rides and discover new horizons with the HJM Apex eBike!
