Bafang Motors
750W/1000W
48V 20Ah
UL-certified LG Battery
24″ / 20″
Front / Rear · 4″ Tires
Up to 80 mi
Estimated Range
480 lbs
Maximum Load
20 mph
Maximum Speed
TriHauler Terra Heavy Duty Fat Tire Utility Electric Trike
T3LJ1
$1,799.00
| Save $1,200 (40%)
Looking for TriHauler Pro? It is the 1000W Rear Drive TriHauler configuration. Select 1000W Rear Drive above to view the available battery and color options.
Free Shipping
15 Day Returns
2-Year Warranty
750W/1000W
Bafang Motors
48V 20Ah
UL-certified LG Battery
24″ / 20″
Front / Rear · 4″ Tires
Up to 80 mi
Estimated Range
480 lbs
Maximum Load
20 mph
Maximum Speed
Add to cart
Before you order
What assembly is required?
The wheels and pedals arrive installed. Install the handlebars, follow the supplied setup instructions, and complete the pre-ride checks before riding. See setup videos.
Which configuration is TriHauler Pro?
TriHauler Pro is the T4, now listed as the 1000W Rear Drive TriHauler. Choose 1000W Rear Drive in the motor options above.
Which models use a torque sensor?
The 750W Front Hub configuration uses a speed sensor. The 750W Rear Drive and 1000W Rear Drive configurations use torque sensors. The front-hub model also has a different frame appearance and a 17.5Ah second battery option.
Is riding a trike the same as riding a bicycle?
A trike handles differently from a two-wheel bicycle. Read your model’s manual and practice starting, stopping, and turning in a clear area before regular use. Slow down before turns and follow the load limits. Three wheels do not make a trike tip-proof.
How far can I ride on a charge?
Range depends on battery capacity, assist level, speed, hills, rider and cargo weight, temperature, and tire pressure. Use the range table and its reference conditions as a guide rather than a guarantee.
Where can I find more compatible accessories?
The add-on list is a shortlist. Browse all accessories for more helmets, mirrors, bags, and other options. Check each item's model and mounting requirements.
Where can I check shipping, returns, and warranty?
Review our Shipping, Return & Refund, and Warranty pages before ordering. Contact HJM for help with your specific product or order.
Bafang Motor Options
Choose the power system that best fits your riding needs. Available configurations include a 750W front hub motor, a 750W rear drive motor, and a 1000W rear drive motor. Each Bafang-powered system delivers smooth, responsive performance for everyday riding, hauling, hills, and varied terrain.
The 750W front hub model uses a speed sensor. The 750W and 1000W rear drive models use torque sensors for pedal assistance. The 1000W rear drive option provides additional power for more demanding rides and heavier loads.
Park with Grace
With a simple press of a button, you activate the pinnacle of convenience and safety. Whether it's a quick pit stop or extended parking, our TriHauler parking system guarantees a seamless experience. The brake locking on both the front and rear wheels enhances overall stability, facilitating smooth mounting, dismounting, and cargo handling, ensuring a secure parking in diverse situations, even on inclines or uneven terrain.
Electric Trike Differential
The TriHauler's differential allows the two rear wheels to have different rotation speeds, ensuring better balance for the tricycle. This feature enhances handling during high-speed maneuvers or turns, minimizing the risk of tipping over or losing control. This ensures a safe and enjoyable riding experience.
Regulatory Notice: Vehicle classification and operating requirements may vary by jurisdiction and motor configuration. Please review applicable local regulations before operating this vehicle on public roads or public-use areas.
WELL-BRAND COMPONENTS
Shimano® 6-speed shift system
It allows you to shift up or down quickly even when riding at high speed. Choose the suitable freewheel under the different riding conditions, it will improve the riding efficiency.
GEMMA® Hydraulic Brake
160mm disc brake system, smooth braking with quick response and rapid heat dissipation, combined with the automatic power-off function of brake, greatly shorten the braking distance.
Kenda® Anti-puncture All Terrain Tire
The 24*4''( 20*4'' rear) tires stay safe with an improved tougher compound and aggressive tread pattern to prevent tires damage. Tires tread pattern Enhanced wet traction and reduced risk of hydroplaning
KMC® Rust-Proof Chain
Equip with world-class KMC chain, it is designed to easily withstand extreme weather conditions, including salt, high humidity, snow and rain storm.
Big Comfortable Saddle
The Big comfortable Saddle provides excellent support on your sit bones with almost no pressure to the perineum area.
Functional Tail Light
HJMBIKE tail light has various functions, such as turn signal, double flashing light and brake light, which provides great safety for riding.
Speed Shift System
Hydraulic Brake
All Terrain Tire
Rust-Proof Chain
Saddle
Functional Tail Light
Shimano® 6-speed shift system
It allows you to shift up or down quickly even when riding at high speed. Choose the suitable freewheel under the different riding conditions, it will improve the riding efficiency.
GEMMA® Hydraulic Brake
160mm disc brake system, smooth braking with quick response and rapid heat dissipation, combined with the automatic power-off function of brake, greatly shorten the braking distance.
Kenda® Anti-puncture All Terrain Tire
The 24*4''( 20*4'' rear) tires stay safe with an improved tougher compound and aggressive tread pattern to prevent tires damage. Tires tread pattern Enhanced wet traction and reduced risk of hydroplaning
KMC® Rust-Proof Chain
Equip with world-class KMC chain, it is designed to easily withstand extreme weather conditions, including salt, high humidity, snow and rain storm.
Big Comfortable Saddle
The Big comfortable Saddle provides excellent support on your sit bones with almost no pressure to the perineum area.
Functional Tail Light
HJMBIKE tail light has various functions, such as turn signal, double flashing light and brake light, which provides great safety for riding.
Technical Specification
| Motor Options | 48V 750W Bafang Front Hub Motor / 48V 750W or 1000W Bafang Rear Drive Motor | ||
| 750W Motor Peak Power & Max Torque | 1026W 76.2 Nm | 1000W Motor Peak Power & Max Torque | 1227W 85.8 Nm |
| Battery | UL-Certified 48V 20Ah (960Wh) Battery with LG Cells | Optional Second Battery | 48V 20Ah (960Wh) |
| Throttle | Thumb Throttle | Pedal Assist | 5-Level Pedal Assist: speed sensor on the 750W Front Hub model; torque sensor on the 750W and 1000W Rear Drive models |
| Charger | 48V 3A Charger | USB Port | 5V USB Charging Port |
| Gearing | Shimano 6-Speed Freewheel (14–34T) | Chain | KMC C7NP Chain |
| Brakes | GEMMA Hydraulic Disc Brakes | Frame | 6061 Aluminum Alloy Frame |
| Fork | Aluminum Alloy Suspension Fork | Suspension | Front Suspension |
| Handlebar | Custom-Formed Aluminum Alloy Handlebar | Seat Post | Promax Seatpost (Size to Be Confirmed) |
| Saddle | Comfort Saddle with Leather Cover | Pedals | VP Aluminum Alloy Platform Pedals |
| Tires | Front: 24" × 4.0" / Rear: 20" × 4.0" Kenda All-Terrain Tires with Reflective Sidewalls and Puncture Protection | Rims | Star Circle Alloy Rims, 36H |
| Spokes | 13-Gauge Stainless Steel Spokes | Headlight | High-Brightness LED Headlight — 226 Lux at 5 Meters |
| Rear Brake Light | Rear Basket-Mounted Taillight with Integrated Brake Light | Turn Signals | Left and Right Rear Fender-Mounted Turn Signals |
| Fenders | Color-Matched Aluminum Alloy Front and Rear Fenders | Rider Height | 5'0" and Above |
| Payload Capacity | 480 lbs | Trike Weight | 95.5 LBS / 109.3 LBS |
Geometry
| A | Handlebar Height 44.9" |
| B | Total Length 73.6"(TriHauler)/ 76.8"(TriHauler pro) |
| C | Wheelbase 44.5" |
| D | Wheel Size 24" x 4.0" |
| E | Seat Height 33.6"-41.4" |
| F | Stand Over Height 16.9" |
| G | Chain Stay Length 19.7" |
| H | Rear Rack 15.3" |
| I | Handlebar Reach 17.3" |
| J | Head Tube 6.5" |
| K | Seat Tube Length 17.3" |
| L | Wheel Size 20" x 4.0" |
| Width | Tricycle Width 30.4"(TriHauler)/ 31.3"(TriHauler pro) |
| Rear basket size (inner) | 17.2" x 14.2" x 7.9" |
| Front basket size | 14.9" x 14.2" x 6.2" |
Distance Range
| PEDAL-ASSIST | |||||
|---|---|---|---|---|---|
|
PAS
|
1 | 2 | 3 | 4 | 5 |
|
Single Battery(20Ah) Range
|
141 Miles | 87 Miles | 70 Miles | 47 Miles | 31 Miles |
|
Dual Battery(20Ah+17.5Ah) Range
|
264 Miles | 162 Miles | 132 Miles | 88 Miles | 59 Miles |
|
Dual Battery(20Ah+20Ah) Range
|
282 Miles | 174 Miles | 140 Miles | 94 Miles | 62 Miles |
| THROTTLE ONLY | ||||||
|---|---|---|---|---|---|---|
|
Single Battery(20Ah) Range
|
30 Miles | empty | empty | empty | empty | empty |
|
Dual Battery(20Ah+17.5Ah) Range
|
57 Miles | empty | empty | empty | empty | empty |
|
Dual Battery(20Ah+20Ah) Range
|
60 Miles | empty | empty | empty | empty | empty |
*The above data is calculated based on a load of 165lbs, zero wind resistance, and a temperature of 25°C, with no uphill conditions.
Distance Range
PEDAL-ASSIST
PAS
1
2
3
4
5
Single Battery(20Ah) Range
141 Miles
87 Miles
70 Miles
47 Miles
31 Miles
Dual Battery(20Ah+17.5Ah) Range
264 Miles
162 Miles
132 Miles
88 Miles
59 Miles
Dual Battery(20Ah+20Ah) Range
282 Miles
174 Miles
140 Miles
94 Miles
62 Miles
THROTTLE ONLY
Single Battery(20Ah) Range
30 Miles
Dual Battery(20Ah+17.5Ah) Range
57 Miles
Dual Battery(20Ah+20Ah) Range
60 Miles
*The above data is calculated based on a load of 165lbs, zero wind resistance, and a temperature of 25°C, with no uphill conditions.
The TriHauler Terra is a heavy-duty fat tire utility electric trike built for stability, versatility, and everyday use. With powerful Bafang motor options, it delivers dependable performance for daily rides, hauling, hills, and varied terrain.
Its stable three-wheel design and low-step frame make riding and getting on and off easier, while spacious front and rear baskets provide practical carrying capacity for groceries, gear, errands, and everyday hauling.
The 750W front-hub model uses a speed sensor, while the 750W and 1000W rear-drive models use torque sensors. All configurations include pedal assistance and throttle control.
